KAER HA06 8-inch 4G Android desk phone with handset

HA06 Android 13 desk phone angled front view

HA06 8-inch vertical touchscreen front view

HA06 Android desk phone with 5MP camera for video calling

HA06 8-Inch 4G Android Desk Phone with VoLTE

The KAER HA06 is an Android 13 4G desk phone designed for offices, reception desks and other fixed indoor communication points. It combines an 8-inch vertical touchscreen, physical handset and 5MP autofocus camera with a manual privacy shutter.

The HA06 supports 4G LTE, carrier-based VoLTE voice and video calling, dual-band Wi-Fi and Bluetooth 5.0. North American, European and Japanese frequency versions are available for different regional projects.


Model:	HA06
Availability:



Inquire

Product Description

Technical Data

Introduction

Android 13

Android 13 with an eight-core processor, 4GB RAM and 64GB internal storage.
8-Inch Touchscreen

800 × 1280 vertical capacitive touchscreen with multi-touch operation.
4G VoLTE Calling

Supports carrier-based 4G LTE and VoLTE voice and video calling.
5MP Camera

5MP autofocus camera with a manual shutter for physical privacy control.

Android 13 with an 8-Inch Vertical Display

The HA06 runs Android 13 and is equipped with an eight-core processor, 4GB RAM and 64GB internal storage. A TF card slot supports storage expansion up to 256GB.

Its 8-inch capacitive touchscreen has an 800 × 1280 resolution and supports multi-touch operation. The vertical layout offers a larger visual interface than a conventional fixed wireless phone, while physical power and volume buttons provide direct access to basic controls.

Software requirements and compatibility should be confirmed according to the intended project before sample testing.
4G LTE and Carrier-Based VoLTE Communication

The HA06 supports 4G LTE connectivity and carrier-based VoLTE voice and video calling. It can be deployed as a fixed wireless phone in locations that use a mobile network instead of a traditional landline.

North American, European and Japanese frequency versions are available for regional projects. VoLTE availability depends on the selected hardware version, SIM card, mobile operator and local network configuration.

Customers should provide the target country and intended carrier so that the required LTE bands can be checked before ordering samples.
5MP Autofocus Camera with Manual Privacy Shutter

The HA06 is equipped with a 5MP autofocus camera for supported video communication functions. A manual privacy shutter allows users to physically cover the lens when video is not required.

This visible privacy control is suitable for shared workstations, reception areas, offices and care facilities where multiple users may access the same device.

Application

Office and Reception Desks

The HA06 provides a fixed 4G communication device for enterprise reception desks, individual offices and shared workstations. Its handset offers familiar calling operation, while the 8-inch touchscreen provides a larger visual interface.
Healthcare and Elderly Care Facilities

The HA06 can be evaluated for fixed communication points in healthcare and elderly care environments. Its touchscreen, VoLTE communication and manually covered camera support use at designated indoor service desks and staff workstations.
Hotel and Service Counters

For hospitality projects, the HA06 can be placed at reception desks and service counters that require a fixed 4G phone with a physical handset, touchscreen and supported VoLTE communication.

Confirm the Right HA06 Configuration

KAER can assist with regional frequency selection, optional hardware confirmation and sample evaluation. Before requesting a quotation, please provide:

● Target country and mobile operator
● Required LTE frequency bands
● VoLTE voice or video calling requirements
● Optional battery or ZigBee requirements
● Estimated order quantity
● Other project-specific requirements

Sample testing is recommended to confirm carrier compatibility, VoLTE availability and the required device functions before volume deployment.

Discuss Your Project

Frequently Asked Questions

What type of product is the HA06?

The HA06 is an Android 13 4G fixed wireless phone with an 8-inch vertical touchscreen, physical handset and 5MP autofocus camera. It is designed for fixed indoor communication workstations.
Does the HA06 support VoLTE video calling?

The HA06 supports the mobile operator's VoLTE voice and video calling functions. Actual availability depends on the selected frequency version, SIM card, carrier service and local network configuration.
Which regional frequency versions are available?

North American, European and Japanese frequency configurations are available. The European and Japanese versions are optional. Please provide the target country and carrier for frequency-band confirmation.
What wireless connections does the HA06 support?

The HA06 supports 2.4GHz and 5GHz Wi-Fi based on 802.11a/b/g/n/ac standards, together with Bluetooth 5.0. ZigBee 3.0 is available as an optional configuration.
What are the camera specifications?

The device is equipped with a 5MP autofocus camera. A manual privacy shutter allows users to physically cover the lens when video is not required.
Is a battery available?

Yes. A 3.7V 2500mAh lithium-polymer battery is available as an optional configuration. The standard power input is DC 12V/1A.
What should be confirmed before ordering samples?

Customers should confirm the target market, mobile operator, required LTE bands, VoLTE service, optional battery, ZigBee requirements and expected order quantity before sample evaluation.

Item		Specification
Basic Information	Product Name	4G Fixed Wireless Phone
	Model	HA06
	Operating System	Android 13
	Processor	Eight-core CPU
	Memory	4GB RAM + 64GB ROM
	Dimensions	235 × 195 × 65mm
	Weight	Approx. 0.9kg
	Color	Black
Display and Camera	Display	8-inch vertical capacitive touchscreen
	Resolution	800 × 1280
	Touch Operation	Multi-touch
	Camera	5MP autofocus camera
	Camera Privacy	Manual privacy shutter
Network and Wireless	Mobile Network	4G LTE
	Voice Service	Carrier-based VoLTE voice and video calling
	North American Frequency Version	LTE FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B66/B71 LTE TDD: B41/B48 WCDMA: B2/B4/B5
	European Frequency Version (Optional)	LTE FDD: B1/B3/B5/B7/B8/B20/B28 LTE TDD: B38/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8
	Japanese Frequency Version (Optional)	LTE FDD: B1/B3/B8/B18/B19/B21/B26/B28 LTE TDD: B41 WCDMA: B1/B6/B8/B9/B19
	Wi-Fi	802.11a/b/g/n/ac, 2.4GHz and 5GHz dual band
	Bluetooth	Bluetooth 5.0
	ZigBee	ZigBee 3.0, optional
Interfaces and Storage	SIM Card	One Nano SIM card slot
	Headset Interface	3.5mm headset jack
	USB	USB Type-C for software upgrades and debugging
	Storage Expansion	TF card, up to 256GB
Power Supply	Power Adapter	DC 12V/1A
Power Supply	Battery	3.7V 2500mAh lithium-polymer battery, optional
Operating Environment	Operating Temperature	0°C to 40°C
	Operating Humidity	10% to 95%, non-condensing
	Storage Temperature	−20°C to 50°C

Network compatibility and VoLTE availability depend on the selected hardware version, SIM card, mobile operator and local network configuration. Please provide the target country and carrier before ordering samples.
