| Model: | |
|---|---|
The HP05 is a desktop-mounted fixed wireless terminal designed for voice communication over cellular networks. It operates on 2G, 3G, and 4G LTE networks with VoLTE support, providing HD voice calling where 4G coverage is available. The device measures 210 × 160 × 85mm and features an ABS matte black enclosure suitable for professional environments. It includes a TNC external antenna connector, standard SIM card slot, and TF card slot for audio recording storage. The unit ships with a DC 5V/0.5A power adapter and a 3.7V/800mAh lithium-ion battery for backup operation. Network switching occurs automatically when 4G signal strength falls below operational thresholds, with no manual configuration required.
Parameter | Specification |
|---|---|
Working Band | 4G: B38/39/40/41/1/3/5/8 3G: B1/5/8 2G: 850/900/1800/1900MHz |
Display | 128 × 64 dot-matrix LCD with white backlight |
Housing Material | ABS plastic with matte finish |
SIM Configuration | Single standard SIM card slot |
Antenna Interface | TNC connector for external antenna |
Mounting Type | Desktop placement with adjustable stand |
Power Input | DC 5V/0.5A via micro-USB port |
Backup Battery | 3.7V/800mAh rechargeable lithium-ion |
Unit Color | Black |
Dimensions | 210 × 160 × 85mm |
Function | Support Status |
|---|---|
Network Compatibility | 2G/3G/4G LTE with VoLTE |
SMS Storage | 300 entries + USIM card capacity |
Phonebook Capacity | 150 entries + USIM card capacity |
External Interfaces | USB port, TF card slot (max 32GB) |
Group Messaging | Supported |
Alarm Clock | Supported |
Calculator | Supported |
Auto Redial | Supported |
Speed Dial | Supported (keys 1-9, 3-second long press) |
Caller ID Display | Supported |
Backlight Timer | Supported |
Call Duration Display | Supported |
Hands-free Mode | Supported with volume adjustment |
Missed Call Indication | Supported |
Message Waiting Indicator | Supported |
SIM Lock | Supported |
Cell Lock | Supported |
Network Lock | Supported |
 | Call Management CapabilitiesThe device supports standard PBX-style call functions including call waiting, call transfer, and call barring. Call recording operates in both automatic and manual modes, with audio files stored on TF card in MP3 format. Recordings may be played back directly through the device speaker or accessed via USB connection to a computer. Four dedicated memory keys (M1-M4) and nine programmable speed dial keys provide one-touch dialing for frequently called numbers. |
When connected to mains power via the included adapter, the device operates continuously without battery dependency. On battery power, the unit provides 4-6 hours of continuous talk time or 120 hours of standby time under nominal network conditions. The 128 × 64 dot-matrix display includes adjustable backlight timing for low-light environments. Menu navigation operates through a four-way directional pad with dedicated Menu, Back, Call, and End keys.
The HP05 is suitable for permanent desktop installation in office environments, hotel front desks, and hospital nurse stations where wired telephone infrastructure is unavailable or impractical. It also operates in temporary workstations, construction site offices, and remote locations where cellular service provides the only communication path. The multi-network fallback capability supports operation in mobile environments including maritime vessels and railway carriages. Multi-language menu support enables deployment across global regions, with frequency band customization available for specific country requirements.
Standard units ship with pre-configured global frequency bands. Custom band configuration is available for orders exceeding 500 units, with lead times adjusted accordingly. Color screen options are available for volume orders. All units include a 12-month warranty covering manufacturing defects. Standard production lead time is 15-20 working days for quantities under 1000 units. Technical support is available via email for configuration and troubleshooting inquiries.
The standard configuration supports 4G bands B1/3/5/8/38/39/40/41, 3G bands B1/5/8, and quad-band 2G GSM. Custom band profiles may be requested for specific regional operator requirements during volume procurement.
Yes. Both in-call recording and local voice recording are supported. Audio files are stored on a user-supplied TF card (up to 32GB capacity). Recording may be set to automatic mode for all calls or activated manually via the dedicated REC key during active calls.
Yes. The device functions normally when powered solely through the DC 5V/0.5A adapter. The backup battery is included for operation during temporary power outages or locations without continuous mains power.
The TF card slot supports cards up to 32GB, which stores approximately 400 hours of MP3-format call recordings at standard audio quality settings.
