◆ High-performance IP phones at competitive prices
◆ Supports high-quality voice calls
◆ LED Display
◆ WiFi 802 b/g/n/ac/ax, 2.4GHz & 5GHz
◆ Supports Opus encoding format
◆ Easy to deploy, easy to manage, and supports web access to the phone
◆ High compatibility, compatible with mainstream SIP-based IP PBX/softswitch/IMS platforms
◆ Supports remote upgrades
Parameter | Details | |
| Complete Machine | Reference Dimensions | Main unit: 172*50*32mm Base: 172*79*27.5mm mm * 172 * 59mm
|
Case Material | ABS + TPU | |
| SIP | Audio Parameters | HD Voice |
Encoding/Decoding: G.711/722/729, AMR-NB/WB, iLBC, Opus | ||
With automatic echo cancellation | ||
DTMF: In-band,Out-of-band,SIP INFO | ||
Phone Features | Supports 1 SIP account | |
Incoming/outgoing calls ; caller ID, ringtone | ||
User Interface | LED display | |
SIP status indicator light, WiFi status indicator light | ||
Network & Security | Supports SIP v1 (RFC2543) and SIP v2 (RFC3261) | |
Supports NAT: STUN, TURN, ICE | ||
Supports RTP/RTCP/SRTP | ||
Supports Qos | ||
Supports IPv4 and IPv6 | ||
Configuration Management | Supported configuration modes: WEB | |
Restore factory settings and restart | ||
OTA | ||
| Network | WiFi | 802 b/g/n/ac/ax, 2.4GHz & 5GHz |
Voice | Trumpet | 1 |
MIC | 1 | |
Power Supply | Input | AC 100~240V |
Output | DC 5V / 1000mA | |
Other | Operating Humidity | 10%-95% |
Atmospheric Pressure | 86-106 kPa | |
Operating Temperature | - 0 ℃ - + 45 ℃ | |
Storage Temperature | -20℃ - +60℃ | |
